| Designation |
Leica Q3 Monochrom |
| Camera type |
Digital 35 mm compact camera |
| Type No. |
6506 |
| Order No. |
19 200 EU/US/CN, 19 201 JP, 19 202 ROW |
| Buffer memory |
8 GB |
| Storage medium |
UHS-II (recommended), UHS-I, SD/SDHC/SDXC memory card |
| Material |
Full metal housing: magnesium die-cast, leather covering, protection type IP52 |
| Operating conditions |
0°C to +40°C |
| Interfaces |
ISO accessory shoe with additional control contacts for Leica flash units, HDMI jack Type D, USB 3.1 Gen 2 Type C up to 10 Gbps |
| Tripod thread |
A 1⁄4 DIN 4503 (1⁄4”) with stainless steel in the base |
| Dimensions |
130 x 80,3 x 92,6 mm |
| Weight |
Approx. 746 g/662 g (with/without battery) |
| Sensor |
|
| Sensor size |
CMOS sensor, 62.39 MP/60.3 MP (total/effective) |
| Processor |
Leica Maestro series (Maestro IV) |
| Filter |
no low-pass filter |
| File formats |
Photo: DNG™ (raw data), DNG + JPG, JPG (DCF 2.0, Exif 3.0) Video: MP4 h.265 / AAC / 48 kHz (16 Bit) h.264 AAC 48 kHz/ (16 Bit)
MOV h.265 / LPCM / 48 kHz (24 Bit) h.264 / LPCM / 48 kHz (24 Bit) ProRes / LPCM / 48 kHz (24 Bit)
|
| Image resolution |
DNG™ 9520 x 6336 Pixel (60,3 MP) 7404 x 4928 Pixel (36,5 MP) 5288 x 3518 Pixel (18,6 MP) JPG 9520 x 6336 Pixel (60,3 MP) 7392 x 4928 Pixel (36,4 MP) 5280 x 3512 Pixel (18,5 MP |
| File size |
DNG™: approx. 70 MB, depending on resolution and image content JPG: depending on resolution and image content Video: max. length: 29 min |
| Bit depth |
DNG™: 14 bit/12 bit JPG: 8 bit |
| Video Resolution |
C8K (17:9) 8192 x 4320 8K (16:9) 7680 x 4320 C4K (17:9) 4096 x 2160 4K (16:9) 3840 x 2160 Full HD (16:9) 1920 x 1080 |
| Video frame rate/bit rate |
MOV C8K (recording to SD) 29,97 fps C8K 4:2:0 / 10 Bit h.265 L-GOP 300 Mbps 25,00 fps C8K 4:2:0 / 10 Bit h.265 L-GOP 300 Mbps 24,00 fps C8K 4:2:0 / 10 Bit h.265 L-GOP 300 Mbps 23,98 fps C8K 4:2:0 / 10 Bit h.265 L-GOP 300 Mbps MOV C8K (HDMI output without HLG/L-Log and without recording to SD) 29,97 fps 8K 4:2:0 / 8 Bit h.265 L-GOP 300 Mbps 25,00 fps 8K 4:2:0 / 8 Bit h.265 L-GOP 300 Mbps 24,00 fps 8K 4:2:0 / 8 Bit h.265 L-GOP 300 Mbps 23,98 fps 8K 4:2:0 / 8 Bit h.265 L-GOP 300 Mbps
MOV C8K (HDMI output with HLG/L-Log or during recording to SD) 29,97 fps C4K 4:2:2 / 10 Bit h.265 L-GOP 300 Mbps 25,00 fps C4K 4:2:2 / 10 Bit h.265 L-GOP 300 Mbps 24,00 fps C4K 4:2:2 / 10 Bit h.265 L-GOP 300 Mbps 23,98 fps C4K 4:2:2 / 10 Bit h.265 L-GOP 300 Mbps
MOV 8K (recording to SD) 29,97 fps 8K 4:2:0 / 10 Bit h.265 L-GOP 300 Mbps 25,00 fps 8K 4:2:0 / 10 Bit h.265 L-GOP 300 Mbps 24,00 fps 8K 4:2:0 / 10 Bit h.265 L-GOP 300 Mbps 23,98 fps 8K 4:2:0 / 10 Bit h.265 L-GOP 300 Mbps
MOV 8K (HDMI output without HLG/L-Log and without recording to SD) 29,97 fps 8K 4:2:0 / 8 Bit h.265 L-GOP 300 Mbps 25,00 fps 8K 4:2:0 / 8 Bit h.265 L-GOP 300 Mbps 24,00 fps 8K 4:2:0 / 8 Bit h.265 L-GOP 300 Mbps 23,98 fps 8K 4:2:0 / 8 Bit h.265 L-GOP 300 Mbps
MOV 8K (HDMI output with HLG/L-Log or during recording to SD) 29,97 fps 4K 4:2:2 / 10 Bit h.265 L-GOP 300 Mbps 25,00 fps 4K 4:2:2 / 10 Bit h.265 L-GOP 300 Mbps 24,00 fps 4K 4:2:2 / 10 Bit h.265 L-GOP 300 Mbps 23,98 fps 4K 4:2:2 / 10 Bit h.265 L-GOP 300 Mbps
MOV C4K 59,94 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 600 Mbps 50,00 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 600 Mbps 48,00 fps 4:2:2 / 10 Bit (SD) h.264 ALL-I 600 Mbps 24,00 fps 4:2:2 / 10 Bit (HDMI) 47,95 fps 4:2:2 / 10 Bit (SD) h.264 ALL-I 600 Mbps 23,98 fps 4:2:2 / 10 Bit (HDMI) 29,97 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 400 Mbps 25,00 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 400 Mbps 24,00 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 400 Mbps 23,98 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 400 Mbps
MOV 4K 59,94 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 600 Mbps 50,00 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 600 Mbps 48,00 fps 4:2:2 / 10 Bit (SD) h.264 ALL-I 600 Mbps 24,00 fps 4:2:2 / 10 Bit (HDMI) 47,95 fps 4:2:2 / 10 Bit (SD) h.264 ALL-I 600 Mbps 23,98 fps 4:2:2 / 10 Bit (HDMI) 29,97 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 400 Mbps 25,00 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 400 Mbps 24,00 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 400 Mbps 23,98 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 400 Mbps
MOV FHD 119,88 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 400 Mbps 100,00 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 400 Mbps 59,94 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 200 Mbps 50,00 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 200 Mbps 48,00 fps 4:2:2 / 10 Bit (SD) h.264 ALL-I 200 Mbps 24,00 fps 4:2:2 / 10 Bit (HDMI) 47,95 fps 4:2:2 / 10 Bit (SD) h.264 ALL-I 200 Mbps 23,98 fps 4:2:2 / 10 Bit (HDMI) 29,97 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 200 Mbps 25,00 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 200 Mbps 24,00 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 200 Mbps 23,98 fps 4:2:2 / 10 Bit (SD & HDMI) h.264 ALL-I 200 Mbps
MOV FHD Slow Motion Sensor: 119,88 fps 4:2:0 / 10 Bit (SD & HDMI) h.265 L-GOP 100 Mbps Recording/Playback: 29.97 fps Sensor: 100,00 fps 4:2:0 / 10 Bit (SD & HDMI) h.265 L-GOP 100 Mbps Recording/Playback: 25,00 fps
MOV FHD ProRes 59,94 fps 422HQ ProRes 454 Mbps 50,00 fps 422HQ ProRes 378 Mbps 29,97 fps 422HQ ProRes 227 Mbps 25,00 fps 422HQ ProRes 189 Mbps 24,00 fps 422HQ ProRes 182 Mbps 23,98 fps 422HQ ProRes 181 Mbps
MP4 8K MP4 8K (recording to SD) 29,97 fps 8K 4:2:0 / 10 Bit h.265 L-GOP 300 Mbps 25,00 fps 8K 4:2:0 / 10 Bit h.265 L-GOP 300 Mbps 23,98 fps 8K 4:2:0 / 10 Bit h.265 L-GOP 300 Mbps MP4 8K (HDMI output without recording to SD) 29,97 fps 8K 4:2:0 / 8 Bit h.265 L-GOP 300 Mbps 25,00 fps 8K 4:2:0 / 8 Bit h.265 L-GOP 300 Mbps 23,98 fps 8K 4:2:0 / 8 Bit h.265 L-GOP 300 Mbps MP4 8K (HDMI output during recording to SD)) 29,97 fps 4K 4:2:2 / 10 Bit h.265 L-GOP 300 Mbps 25,00 fps 4K 4:2:2 / 10 Bit h.265 L-GOP 300 Mbps 23,98 fps 4K 4:2:2 / 10 Bit h.265 L-GOP 300 Mbps
MP4 4K 59,94 fps 4:2:0 / 10 Bit (SD & HDMI) h.265 L-GOP 100 Mbps 50,00 fps 4:2:0 / 10 Bit (SD & HDMI) h.265 L-GOP 100 Mbps 29,97 fps 4:2:0 / 8 Bit (SD & HDMI) h.264 L-GOP 100 Mbps 25,00 fps 4:2:0 / 8 Bit (SD & HDMI) h.264 L-GOP 100 Mbps 23,98 fps 4:2:0 / 8 Bit (SD & HDMI) h.264 L-GOP 100 Mbps
MP4 FHD 59,94 fps 4:2:0 / 8 Bit (SD & HDMI) h.264 L-GOP 28 Mbps 50,00 fps 4:2:0 / 8 Bit (SD & HDMI) h.264 L-GOP 28 Mbps 29,97 fps 4:2:0 / 8 Bit (SD & HDMI) h.264 L-GOP 20 Mbps 25,00 fps 4:2:0 / 8 Bit (SD & HDMI) h.264 L-GOP 20 Mbps 23,98 fps 4:2:0 / 8 Bit (SD & HDMI) h.264 L-GOP 24 Mbps
|
| Lens |
|
| Designation |
Leica Summilux 28 f/1.7 ASPH., 11 lenses in 9 segments, 3 aspherical lenses |
| Lens filter thread |
E49 |
| Digital zoom |
Optionally approx. 1.25x (equivalent to 35 mm), approx. 1.7x (equivalent to 50 mm), approx. 2.7x (equivalent to 75 mm), or approx. 3.2x (equivalent to 90 mm) |
| Image stabilization |
Visual compensation system for photos and video recordings |
| Aperture range |
F1.7 to F16 in 1⁄3 EV increments |
| Shutter |
|
| Shutter type |
Mechanical central shutter or optional electronic shutter |
| Shutter speeds |
Mech. shutter: 60 min to 1⁄2000 s Electro. shutter function: 60 s to 1⁄16000 s Flash Synchronization: up to 1⁄2000 s |
| Shutter button |
Two-stage (1st stage: Activation of the camera electronics including autofocus and exposure metering, 2nd stage: Taking the picture) |
| Self-timer |
Delay time: 2 s or 12 s |
| Drive Mode |
Single, Continuous Shooting, Interval Shooting, Exposure Bracketing, Multi-Shot
Continuous shooting: 2 B/s, 14 Bit, AF - 4 B/s, 14 Bit, AF - 5 B/s, 12 Bit, AF Mech. or electr. shutter Automatic settings (exposure settings in operating modes P/A/S, automatic white balance and autofocus) are implemented individually for each frame.
7 B/s, 14 Bit, AF - 9 B/s, 12 Bit, AF - 15 B/s, 12 Bit, AF Electr. shutter Automatic settings (exposure settings in operating modes P/A/S, automatic white balance and autofocus) are implemented for the first frame, and are then applied for each subsequent frame in the same picture series.
|
| Focusing |
|
| Focus range |
30 cm to ∞ With macro setting: from 17 cm |
| Focus mode |
Automatic or manual With manual setting: optional magnifying glass function (Auto Magnification) and edge marking (Focus Peaking) available as focus assist |
| Autofocus system |
Contrast detection |
| Autofocus modes |
Intelligent AF (automatically refocuses as soon as something changes in the scene), AFs, AFc, AF setting can be saved, optional Touch AF |
| Autofocus metering methods |
Spot (can be shifted), Field (can be shifted and scaled), Multi-field, Zone (can be shifted and scaled), Eye/Face/Body Detection, Animal Detection (Beta), Tracking |
| Autofocus metering fields |
315 |
| Exposure |
|
| Exposure metering |
TTL (exposure metering through the lens), with working aperture |
| Metering principle |
Exposure metering is done by the image sensor for all exposure metering methods (in Live View mode and in rangefinder mode) |
| Exposure metering methods |
Spot, Center-Weighted, Highlight-Weighted, Multi-Field |
| Exposure modes |
Program AE mode (P) Aperture-priority mode (A): manual aperture setting Shutter-priority mode (S): manual shutter-speed setting Manual (M): manual setting for shutter speed and aperture Various fully automatic variants (Scene Mode): AUTO, Digiscoping |
| Exposure compensation |
±3 EV in 1⁄3 EV increments |
| Automatic bracketing |
3 or 5 frames, graduations between shoots up to 3 EV, in 1⁄3 EV increments additional optional exposure compensation: up to ±3 EV |
| ISO sensitivity range |
Foto: Auto ISO 200–ISO 200 000 Manual: ISO 100–ISO 200 000 Video: Auto ISO 100–ISO 200 000 Manual ISO 100–ISO 200 000 |
| Dual Basis ISO settings |
Foto: Low Basis-ISO ISO 100–ISO 560 High Basis-ISO ISO 640–ISO 200 000 Video: Low Basis-ISO ISO 100–ISO 560 High Basis-ISO ISO 640–ISO 200 000 |
| Flash |
|
| Flash unit connector |
Via the accessory shoe |
| Flash sync time |
1⁄2000 s, slower shutter speeds available. High-speed shutter times between 1/2500 s and 1/16000 s are available only via the electronic shutter. Shorter shutter speeds, however, are only available via the mechanical shutter. |
| Flash exposure metering |
Using center-weighted TTL pre-flash metering with Leica flash units (SF 26, SF 40, SF 58, SF 60, SF 64) or with system-compatible flash units, remote controlled flash SF C1 |
| Flash exposure compensation |
SF 40: ±2 EV in 1⁄2 EV increments SF 60: ±2 EV in 1⁄3 EV increments |
| Equipment |
|
| Microphone |
Stereo |
| USB Audio |
Compatible RØDE USB audio devices include: VideoMic GO II, VideoMic NTG, Wireless GO II, Wireless ME, and other supported USB microphones. |
| Speaker |
Mono |
| WLAN |
WLAN function for connecting to the Leica FOTOS app. The Leica app is available from the Apple App Store™ or the Google Play Store™ Maximum output (e.i.r.p.): <14 dBm, encryption method: WLAN-compatible WPA™/WPA2™/WPA3™ |
| Bluetooth |
Bluetooth 5.0 LE: Channel 0–39 (2402–2480 MHz), maximum output (e.i.r.p.): 10 dBm |
| GPS |
Not available everywhere due to country-specific legislation; can be added via the Leica FOTOS app. Data is written to Exif header of the picture files. |
| Menu languages |
English, German, French, Italian, Spanish, Portuguese, Russian, Japanese, Traditional Chinese, Simplified Chinese, Korean |
| Power supply |
|
Rechargeable battery (Leica BP-SCL6) |
Lithium-ion rechargeable battery, rated voltage: 7.2 V (DC); capacity: 2200 mAh (min.), 302 shots (based on CIPA standard), 1535 shots (based on CIPA standard with adapted shooting cycle*) Manufacturer: Panasonic Energy (Wuxi) Co. Ltd., Made in China
*Cycle 1: Switch on, 1st shutter release after 5 s, one shot every 3 s, the camera switches off after 10 shots (Auto Power Off) and switched back on after a waiting time of 5 min.
*Cycle 2: Switch on, 1st shutter release after 5 s, one shot every 3 s, the camera switches off after 50 shots (Auto Power Off) and switched back on after a waiting time of 5 min.
These cycles are repeated alternately until the battery is empty.
|
USB-C power adapter (Leica ACA-SCL6) (optional) |
Input: AC 100–240 V, 50/60 Hz, 0.25 A, automatic switchover; Output: DC 5 V/9 V, 3 A; Manufacturer: Salom Electric (Xiamen) Co., Ltd., Made in China |
Charger (Leica BC-SCL4) (optional accessory) |
Input: AC 100–240 V, 50/60 Hz, 0.25 A, automatic switchover; output: DC 8.4 V 0.85 A; manufacturer: Salom Electric (Xiamen) Co., Ltd., Made in China |
USB-C DC Coupler (Leica DC-SCL6) |
Input: DC 9 V/3 A (min.), Output: DC 9 V (with ACA-SCL6), supports USB PD 3.1, Manufacturer: Salom Electric (Xiamen) Co., Ltd., Made in China. |
| Charging via USB |
During operation: 9 V/3 A (min. 27 W) With camera switched off: 5 V/1500 mA (2.5 W or greater) |
| Wireless Charging |
Optimal performance with 9 V chargers (10 W Charging Pad required) |
| Rated values for input voltage/power |
7.2 V 2.3 A (battery), 5 V 3.0 A / 9 V 2.5 A (USB) |
